Carrying capacity: 15 tonnes | Cubic Meters Heaped: 16 to 21m³
- Carrying capacity: 15 tonnes
- Cubic meters heaped: 16 to 21m³
- Body width 1500mm
- Heavy duty fully welded construction
- Handles all manure types and other materials
- Twin dynamically balanced hardened BORON Horizontal Beaters
- 10mm thick beater flights from heat treated BORON steel
- Reversible hardened BORON shredding cutters
- Large diameter spinning discs with adjustable blade position
- Duplex chain driven beater
- Automatic lubrication on beater drive-line
- One piece auger gearbox arrangement
- Spinning disc gearbox protection via shearbolt
- Horizontal Beater protection via torque clutch
- Robust, purpose built agricultural axle for application
- Long lasting composit floor shaft bearings
- Floor protected by cross line relief valve
- High torque hydraulic motor
- Quick fit socket on full width floor slats
- Calibrated 16mm grade 80 high tensile floor chains
- High tensile rear floor shaft
- Variable floor speed control
- 1000 rpm PTO speed
- Single pole drawbar for tighter turning circle
- Hydraulic brakes & handbrake
- Full road lighting
- Choice of standard colour, fully shot blasted with 2 pack paint finish
- Choice of screwjack or pick up support
- 3 years warranty, details available upon request
