Krone Swadro 1400Plus

KRONE FOUR ROTOR CENTRE DELIVERY RAKES

Krone Swadro 1400Plus

The new and updated Swadro 1400 Plus offers the best windrow formation not just due to the cam track design, but the different rotational speed between the front and the rear rotors. This results in no rpoing of the material which can be seen in machine of this class. The larger gearboxes and PTO drive shafts results and more reliability and keep professional users in the paddock for longer.

• Krone rakes excel with their well shaped windrow formation. This ensures that the following harvesting equipment can increase forward speed and productivity as well as produce the perfect product for example well shaped square bales or even flow of crop in the forager.
• There are two secrets in this machine. One is behind Krone’s steep cam track angle. This allows the tine arms to pivot very quickly which results in the tines to lift up fast to form an even filled square windrow. The second is the faster speed of the front two rotors over the rear rotors for no roping effect.
• The standard centre swath curtain can be used when forming the windrow.

• Customers tell us our rakes are the cleanest in the field. Our tines are pointing forwards which means when the tine loads up the distance to the ground decreases, to put all that valuable crop into the windrow rather than leaving it behind.
• The new lift tine is even more forward facing to be exact about 100mm up the tine rod. This simple improvement results in the crop running up the tine rod, so that less material is dragging along the bottom of the tines which reduces crop losses, crop contamination and allows operators to finally use rotary rakes at faster forward speeds.
• Krone tines are strong using 3 coils and 10.5mm rods. 4 double tines per rotor are standard and the Swadro 1400 Plus offers 13 tine arms per rotor on the front and 15 tine arms on the rear.
• Swadro 1400 Plus offers electric rotor height adjustment from the cabin with height shown on the LCD screen. New on this Plus model is the ability to adjust one rotor followed by a push of a button so that all other three rotors adjust to the same tine height.
